Capture a sideview video from 3 meters of the relaxed cattle and hold it tight until the capturing is finished. Make sure there are no obsticles in between.
You need the following things to connect the agroninja beefie3d™ camera with your Android smartphone:
The agroninja beefie™ depth camera (you find it in the package)
Self adhesive metal plate (you find it in the package)
Android OS smartphone (this is not included)
USB cable (you find it in the package)
The assembly
1. step)Fix the self-adhesive metal plate to your Android smartphone or simply place it under your cover.
Pull off the protective film from the adhesive surface of the back of the self-adhesive magnetic plate and stick it on the back of your phone. Or simply place the metal plate under your cover without sticking it on your phone.You should fix the self-adhesive metal plate to the back, near the bottom of
your Android smartphone as you can see on this image.
Note – some Android smartphones have a smart-case function enabled and this may cause an issue that the screen goes off when the beefie camera is attached (caused by its magnet, which is similar to the smart cases). If you experience this issue, just move the self-adhesive metal plate an inch higher or disable smart-case function in your Android settings.
2. step)Attach the agroninja beefie™ camera to your Android smartphone
Attach the beefie3d™ camera to the self adhesive metal plate on the back of your phone and connect the beefie3D™ camera to your phone with the USB C or Micro USB cable. Launch the agroninja beefie3d™ application.
Advice: Be sure to connect the beefie™ depth camera before every use of the application.
If you have any questions during the startup process, you can find the digital user manual on our Youtube channel.
or visit our helpdesk on our website.
2 step) Start the agroninja beefie3D™ app on your smartphone
3 step) Log in with your e-mail address and password, associated with your license.
Advice: Forgot your password? Just hit the “Forgot password” link and reset it. We are going to send you a link to your email associated with your license. Follow the link and you will be directed to a screen where you can set your new password.
4 step) Connect the agroninja beefie3D™ camera to your phone with the USB C or Micro USB cable.
Capturing with agroninja beefie3d
Start the weighing process by tapping the “camera” icon on the main screen.
Start capturing
The ideal measurement distance from the target animal is from 1,5 to 3 meters. Stand perpendicular to the animal and hold the phone straight. You need to keep the target animal in the middle of the screen. Press the recording icon on the right side of the screen to start the capturing.
Capturing will take around 6-8 seconds, please check the indicator on the top. When capturing is over the app automatically will send you to the next screen.
Capturing tips:
Capturing on the pasture is best when the sun is behind you (avoid capturing opposing strong sunlight)
Avoid mixed lights on the target cattle (when they are in the shadows, but some parts are covered with sunlight)
In the barn capture the animal with light sources behind you (make sure the surrroundings behind the cattle is neutral)
When the app suggest so, change the environment or time (later in the afternoon, or cloudy days, roofed folds instead)
The whole body of the cattle must be visible, make sure the cattle is in the middle of the screen, Its back, head and legs clearly visible.
Avoid capturing in deep grass, or hay, since the whole body must be visible
Enter cattle details
In order to finish your measurement after you successfully captured the animal you have to record:
Eartag / Identification number of your cattle
Breed type
Gender
What breed types are supported?
With agroninja beefie3d™ you can weigh pure- and mixed breeds as well. Supported breeds are tested and validated.
If your breed type is not supported, please contact our customer service.
Pure breeds
Aberdeen Angus (Black or Red)
Blonde d’ Aquitaine
Charolais
English Longhorn
Fleckvieh
Holstein Friesian
Hereford
Limousin
Murray Gray
Nelore
Norwegian Red
Palmera
Simmental
Hit “Breed” and select your breed type.
Mixed breeds
You can register your crossbreeds before weighing in Settings screen and Crossbreeds section.
Add a new crossbreed by selecting the breed types and its ratios and save them.
After you captured an animal just hit “Breed” and go to the second tab “Crossbreeds” and select custom mixed breed type.
Weighing results
After tapping the “blue check mark” icon the weighing is completed. The weight, calculated by agroninja beefie3D™ app will be displayed. Save the result of the weighing by tapping the “Save and finish” button and you can start the next weighing process.
Results, Export
Your weighings can be accessed by tapping the “Listing” icon on the home screen.
You can find your results grouped by Cattle IDs.
You can export to XLS/delete/move the results by selecting the checkboxes before the data-row and then tapping the “vertical 3 dots” icon in the upper right corner. Synchronize the weighing results with agroninja hub™ by tapping the “cloud” icon. Please note you need to connect to your hub account in the settings menu first. Network connection is needed for both operations.
Meet agroninja beefie3d™
agroninja beefie3d™ is a digital scale for measuring cattle weights running on android smartphones.
Specification
agroninja beefie3d™ is an innovation for cattle breeders and holders. Here are a few technical things to know!
Compatibility
agroninja beefie3d™ runs on Android smartphones, however there are specific models and OS versions where the 3d camera works perfectly. We recommend Android 11 and HiSilicon and Qualcomm chipsets. Please check your phone's specifications or contact our customer service if you want to be sure your smartphone is compatible with agroninja beefie3d™ .
Installation
Download agroninja beefie3d™ app from the Google Play Store, search for "beefie 3d" and install it on your device. When the install is complete, start the app. You will be asked to enter your email address and password, then just connect your camera with the USB cable to start measurements.
Accuracy
the weight calculated by agroninja beefie3d™ is 95% accurate to the real live weight, however the app excludes current feeding, excreta, possible mud, pile, embryos or any other environmental influencing factors (like hot or cold weather) of the gross (scaling) weight.
Breed types
Use agroninja beefie 3d on Aberdeen Angus (Black or Red), Blonde d’ Aquitaine
Charolais, Limousin, Holstein Friesian, Hereford, Simmental, Nelore, and crosses of these above in any ratio. If your breed type is not supported, please contact our customer service.
Monitoring daily weight gain
You can easily monitor your herd's ADG with beefie 3d
Make stressless cattle weighings with agroninja beefie3d™
Connect the app with our cloud based agroninja hub™ herd management system
Login to agroninja hub™ and see all the weight gains and fattening trends from birth to sale
More than just weighings
Order agroninja beefie3d™ and you get full access to agroninja hub™ herd management system to record all your data
Herd management
Search, list, filter your cattle as you wish. Create farms, barns and pastures and move your cattle among them in groups. Make the necessary administration more comfortable for yourself.
Workflows
Record all the data of cattle movings, purchases, sales, breeding, calvings. Stores your partners data like
Reports
Our reports give you pure information about the fattening performance of your cattle. See the Average Daily Gains of a group or individual. See the under and overperforming animal, based on your fattening goals.
